120 FPS USB Camera Module with Advanced Digital Sensors for Rich Colors and Imaging

Name: 120 FPS USB Camera Module with Advanced Digital Sensors for Rich Colors and Imaging
Brand: Sinoseen
Price: 1 USD

Quality 120 FPS USB Camera Module with Advanced Digital Sensors for Rich Colors and Imaging wholesale

Brand Name : Sinoseen

Model Number : SNS-SM1159-V1.0

Certification : RoHS

Place of Origin : China

MOQ : 5

Price : negotiable

Payment Terms : T/T

Supply Ability : 500000 pieces/month

Delivery Time : 2-3week

Packaging Details : Tray+Anti-static bag in carton box

Stable Temperature : 0°C to 50°C

Dsp : USB2.0 DSP

Data Storage : Video, Pictures

Precision : ≥5mil

Standard Configuration : USB3.0 High Speed

Chip Type : OV5648

Image Resolution : 640*480

Image Sensor : CMOS

Keywords : IP Camera Module

Distortion : ＜22%

Interface : USB

Gpu : Mali-T860

Max Pixel Rate : 28Mp/s

Snr : ≥50db

Sensor Type : CMOS

Contact Now

The Sinoseen 1/4 "CMOS OV9281 image sensor module is equipped with advanced digital sensors that support resolutions up to 120 FPS. It performs well in high resolution and low light environments, making it ideal for applications such as video conferencing, surveillance, and industrial inspection. The module provides rich colors and high-quality imaging, supports USB2.0 plug and play, and is compatible with multiple operating systems. For those looking for superior image performance.

Signal		SNS-SM1159-V1.0	REMARKS
Image Sensor Size(图像感光尺寸)		1/4 inch
Effective Pixels(有效像素)		1280H*800V
Pixel size(像素点大小)		3 um*3 um
Optical distortion(畸变)		<-1.2%
Image sensor Data output(数据输出类型)		Raw Bayer 10bits
Video output(输出格式)		MPJG/YUV
Maximum Frame Rates(分辨率和帧率)		2560800 120FPS 1280800 120FPS 1280792 120FPS 2560720 120FPS 1280720 120FPS 1280712 120FPS 1600600 120FPS 800600 120FPS 800592 120FPS 1280480 210FPS 640472 210FPS 1280400 210FPS 640400 210FPS 640392 210FPS 640480 210FPS 640240 210FPS 320240 210FPS 320232 210FPS	MPJG
SNR max(信噪比)		TBD
Dynamic range(动态范围)		TBD
Min. Illumination(最低照度)		TBD
Digital interface(连接接口)		USB2.0	线长1.5米
Transfer rates(接口速度)		480MB/S
Power requirements(电源)		5V±5%
Storage temperature储藏温度		-20℃to70℃
operating temperature 工作温度		-10℃to60℃
Power Consumption (功率)	NO LED	/
	IR-LED	/
PCB printig ink		black
OS(支持系统)		Windows XP /vista/seven/8.1/10/Mac /Android/linux2.6.2(include UVC )
Lens view (默认镜头)		M12*P0.5	LENS
Lens Construction 镜头结构		1G5P+650IR
F/NO光圈		2.4±5%
EFL 有效焦距		2.6 mm±5%
FOV 角度		D :83°±3°
对焦方式		定焦
拍摄距离		60cm-∞
